Marble Pump!
Overview
The Marble Pump is a bidirectional pump that can lift a stack of marbles against the force of gravity to create self-recirculating Stacks! The Track is powered off USB Type C Power Delivery (PD), and will take your Stacking experience into the realm of mesmerizing, hypnotizing Perpetual Stacks!
The Marble Pump is the beating heart of the TrackStacker ecosystem, and is the first ever powered Track! The Pump is powered by USB C Power Delivery (PD) and has 3 DIP switches to select one of 5 possible PD voltages (5V, 9V, 12V, 15V and 20V) to give you 5 speeds to choose from, or to match your Pump to the power supply you have available.
The Marble Pump is fully reversible, and can pump marbles in either direction. This feature is very useful for bleeding marbles out of a Stack when cleaning up!
Application Notes
Two <90 Tracks can also be combined to create an S shaped redirect as shown below. Multiple S Redirects can be combined to create a wiggle shape. This shape can be expanded to any aspect ratio by interspersing Straight Tracks of desired lengths.
Note
There is something noteworthy here!
Warning
There is something noteworthy here!
Bill of Materials
Printed Parts -
- x1 Pump Body - Print in PLA
- x1 Pump Back - Print in PLA
- x1 Pump Ramp - Print in PC
- x1 Pump Wheel - Print in PC/PETG or machine from aluminum
Hardware -
- 4x ⌀6mm ↧2mm Magnets
- 10x ⌀8mm ↧3mm Magnets
- x9 M2 brass heat-set inserts
- 2x M2x8mm Socket Head Cap Screws - cover screws
- 1x M2x8mm Socket Head Cap Screws - ramp screw
- 6x M2x8mm Socket Head Cap Screws - back screws
